Multipoint Raman spectra included on CD ROM
Typical Raman spectrum of a single layer film on Copper Foil
Explanation of Raman spectrum
- Raman spectroscopy is used to check the presence of a D peak in graphene samples. If a D peak is present, then this can indicate defects in the sample, such as cracks or flaking.
- The ratio of the heights of the 2D peak and the G peak indicate the number of graphene layers.
2D>G : Single-layer
2D=G : Double layer
2D<G : more than triple layer
- 3 measurements for every sample are taken and presented on the same graph.
Optical Microscope Image of Single-layer Graphene on Copper foil
Properties of single-layer graphene
- Graphene quality and thickness are confirmed by Raman spectroscopy.
- Multi-point Raman data are provided with every sample.
- Graphene layer is continuous with few small multilayer islands and overall coverage exceeding 95%.
- Sheet resistance is < 1,000 ohm per square.
- Optical transmission is > 95%.
- Copper Purity : over 99.95%
- Copper foil thickness: 35 micron.
- All samples are manufactured in our lab in Japan.
- Shipping: Please allow 3-5 business days by International EMS or 2-3 business days by DHL or FedEx.
